High-Efficiency PFC Choke | 10W to 2000W Power Range
Product Overview High-performance Power Factor Correction (PFC) Chokes designed to minimize harmonic distortion and improve active power in switch-mode power supplies (SMPS) and industrial electronic applications. Available in various core geometries (Toroid, ETD, EE) to suit specific space and magnetic performance requirements.
Power Rating & Core Size Guide | Core Size | Estimated Power Rating | | :— | :— | | 5mm – 15mm | ≤ 10 W | | 15mm – 30mm | 50 W – 300 W | | 30mm – 50mm | 300 W – 800 W | | 50mm – 75mm | 800 W – 2000 W |
Specifications
|
Winding Construction
|
Single winding |
|
Core Shape
|
Toroid, ETD, EE |
|
Core Size
|
5mm - 15mm : ≤10 W15mm - 30mm : 50-300 W30mm - 50mm : 300-800 W50mm - 75mm : 800-2000 W |
|
Bobbin Pin Type
|
SMD, Through hole, fly wire |
|
Wire Type
|
Enamelled copper wireTriple / Fully insulated wire (TIW/FIW)Litz / Multi-Strand wire |
|
Wire Size
|
0.15–0.35 mm0.3–0.8 mm0.6–1.2 mm1.0–2.5 mm |
|
Packaging Options
|
Tray, Reel |
|
Standards
|
RoHS |
|
Operating Temperatures
|
130°C, 155°C |
